Nissan Micra K11 Haltech Turbo Base Map - FREE DOWNLOAD

TUNERS CAN CHARGE £120+ FOR A REMOTE BASE FILE CALIBRATION...

OURS IS FREE!

This free Haltech base map has been created to help get your newly turbocharged Nissan Micra K11 Distributor / Dizzy engine started and idling for the first time.

The idea is simple. Get the engine running, carry out your initial checks and get the car ready to go to your professional tuner.

We're providing the file completely free of charge to help the K11 community.

Feeling generous? We do accept "Beer Tokens" to help keep the workshop fuelled!

SEND ME BEER TOKENS!

https://shorturl.at/nlkba

⚠️ DISTRIBUTOR / DIZZY ENGINES ONLY

THIS BASE MAP IS FOR DISTRIBUTOR / DIZZY K11 ENGINES ONLY.

It is NOT intended for Coilpack engines.

If your vehicle has been engine swapped, loom swapped or converted between ignition systems, identify the actual engine management and ignition configuration rather than relying on the vehicle's registration year.

⚠️ IDLE-ONLY BASE MAP - DO NOT DRIVE THE VEHICLE

This is extremely important.

THIS IS NOT A FINISHED ECU CALIBRATION.

THIS IS NOT A ROAD MAP.

THIS IS NOT A BOOST MAP.

DO NOT DRIVE THE VEHICLE USING THIS FILE.

The calibration has been created purely as a starting point to allow a suitable turbocharged K11 to be started and operated under light-load idle conditions.

Its purpose is to allow you to:

• Confirm the Engine Starts
• Establish a Stable Idle
• Check for Fuel Leaks
• Check for Oil Leaks
• Check for Coolant Leaks
• Check Turbo Oil Feed & Return
• Check Intercooler / Boost Pipework
• Verify Basic Sensor Operation
• Check for Obvious Installation Problems
• Load the Vehicle onto a Trailer
• Transport the Vehicle for Professional Mapping

That's it.

What You Should NOT Do

Under no circumstances should this file be treated as a finished calibration.

DO NOT:

• Drive the Vehicle on the Road
• Take it for "Just a Quick Test Drive"
• Apply Significant Throttle under Load
• Attempt to Make Boost
• Carry Out Full-Throttle Testing
• Perform Power Runs
• Assume the Fuel or Ignition Calibration is Correct for Your Engine

Even if the engine appears to run perfectly at idle, this does not mean the calibration is suitable under load.

⚠️ Base Ignition Timing MUST Be Verified

On the intended distributor-engine configuration, the distributor must be set in the required fully advanced position and the actual ignition timing must be physically verified.

IGNITION TIMING MUST BE CHECKED WITH A TIMING LIGHT.

Do not assume that the timing value displayed by the ECU automatically represents the actual ignition timing being delivered by the engine.

Trigger configuration, distributor position and other setup differences can result in the commanded and actual ignition timing being different.

This must be checked and correctly configured by somebody who understands the Haltech system and Nissan distributor ignition arrangement.

Your Engine Setup Still Needs to Be Checked

A base map cannot account for every combination of:

• Injector Size
• Injector Characteristics
• Fuel Pressure
• Fuel Pump
• Turbocharger
• Wastegate
• MAP Sensor
• Intake Air Temperature Sensor
• Coolant Temperature Sensor
• Trigger Configuration
• Engine Capacity
• Compression Ratio
• Fuel Type
• Wiring
• Sensor Calibration

Before starting the engine, the ECU configuration must be checked against the hardware actually fitted to the vehicle.

Do not assume that downloading the file and pressing START makes it automatically compatible with your engine.

Why Can't I Drive on It?

An engine operating at idle is under very little load compared with an engine accelerating a vehicle or producing boost.

Once load and boost increase, correct ignition timing and fuel delivery become absolutely critical.

An unsuitable calibration under load can result in:

• Detonation
• Pre-Ignition
• Excessively Lean Air/Fuel Ratios
• Excessively Rich Running
• Excessive Exhaust Gas Temperatures
• Spark Plug Damage
• Piston Damage
• Ringland Failure
• Head Gasket Failure
• Turbocharger Damage
• Complete Engine Failure

A car starting and idling nicely tells you nothing about whether the calibration is safe at 5,000RPM and under boost.

Professional Dyno Calibration Required

Before the vehicle is driven or operated under significant load, it must receive a complete custom calibration from a suitably experienced professional tuner.

A professional tuner should verify and configure the complete engine management system for your particular engine and hardware combination.

This includes appropriate checks of:

• Base Ignition Timing
• Trigger Configuration
• Injector Configuration
• Fuel Pressure
• Sensor Calibration
• Fuel Tables
• Ignition Tables
• Boost Control
• Rev Limits
• Engine Protection Strategies
• Air/Fuel Ratio
• Knock Behaviour where applicable

The free file is simply intended to help bridge the gap between finishing your turbo conversion and getting the car onto the dyno.

FREE DOWNLOAD

No £120 remote base-map charge here.

Download it. Check your configuration. Start the car. Check for leaks. Make sure everything works.

Then put it on the trailer and take it to your tuner.

Download Password: 0121

Use at Your Own Risk

This base calibration is provided free of charge as a starting-point calibration only.

By downloading or using the file, you acknowledge that vehicle and engine configurations vary and that the calibration must be checked for compatibility with the specific hardware, wiring, sensors and engine management configuration fitted to your vehicle.

GizFab Motorsport Developments makes no guarantee that the file will be suitable for any particular engine or vehicle configuration without adjustment.

The user and/or tuner is responsible for verifying all ECU settings, sensor calibrations, injector data, trigger configuration, base ignition timing and other critical parameters before operating the engine.

GizFab Motorsport Developments accepts no responsibility for engine, turbocharger, drivetrain, electrical or consequential damage resulting from incorrect configuration, inappropriate use of the calibration or operation of the vehicle under load before professional calibration.

DO NOT DRIVE THE VEHICLE ON THIS BASE MAP.
